J300P-7 SPLINED MIDSHIP TUBE SHAFTS
Slip Yoke Design For Use with Outboard Slip Yokes
L
Length
of
Spline
K
End of
Spline
to Point of
Weld
S
t
y
l
e
Y
End of
Spline to
Bearing
Shoulder
B
Shoulder
Diameter
G
Length of
Shoulder
Midship
Tube Shaft
Part
Number
Tube
Diameter
Wall
Thickness
Fits Tube
15 Important: See Safety Information in General Information Section (J300P-GI)
• Part is discontinued „ Part is available until supply is exhausted Ž Not sold separately
1.7500-34 Spline
2.185 Bearing Diameter (C)
3.500 .134 — 7.000 3 2.031 — — 5-53-331•
Has .625-18 thread at spline end
1.7520-26 Based On 27 Involute Spline
1.772 Bearing Diameter (C)
3.500 .095 8.902 9.693 2 3.500 2.154 .554 70-53-51
Use boot 212146X, order separate
4.000 .083 8.102 8.902 2 3.500 2.154 .554 70-53-11
Use boot 212146X, order separate
4.000 .083 8.902 9.693 2 3.500 2.154 .554 70-53-21•
Use boot 212146X, order separate
1.9370-29 Based On 30 Involute Spline
1.968 Bearing Diameter (C)
4.000 .095 8.720 9.862 2 4.000 2.441 — 100-53-11•
Use boot 212146X, order separate
4.000 .095 9.520 10.661 2 4.000 2.441 — 100-53-21
Use boot 212146X, order separate
1.9370-30 Involute Spline
1.968 Bearing Diameter (C)
4.000 .095 8.906 10.000 2 4.000 2.438 .812 90-53-21
Mates with 90-3-41X
4.000 .134 8.906 10.000 2 4.000 2.438 .812 90-53-41
1.9830-31 Involute Spline
2.436 Bearing Diameter (C)
3.500 .134 — 9.540 3 2.810 2.400 — 70-53-81
.268 Keyway. Metric Thrd. Used w/pillow block
