J300P-7
SPLINED MIDSHIP TUBE SHAFTS
Companion Flange or End Yoke Design
11
Important: See Safety Information in General Information Section (J300P-GI)
•
Part is discontinued
Part is available until supply is exhausted
Not sold separately
L
Length
of
Spline
K
End of Spline
Spline to
Point of Weld
Thread Size
S
t
y
l
e
Y
End of Spline
to Bearing
Shoulder
B
Shoulder
Diameter
G
Length of
Shoulder
Midship
Tube Shaft
Part Number
Tube
Dia.
Wall
Thickness
Fits Tube
2.350-16 Spline
2.362 Bearing Diameter (C)
3.500 .188
4.000
5.310
2 2.750
1.250-18
2.880
.810
6.5-53-21•
4.000 .134
4.000
5.312
2 2.625
1.250-18
2.875
.812
6-53-311
4.500 .134
4.000
5.312
2 2.750
1.250-18
2.875
1.312 6.5-53-91
4.500 .259
4.000
5.438
2 2.750
1.250-18
2.875
.812
6.5-53-51
2.350-46 Involute Spline
2.362 Bearing Diameter (C)
4.000 .134
4.000
5.312
2 2.625
1.250-18
2.875
.812
6.3-53-21
Spline has helix on tooth. End yokes will be a tight fi t.
4.330 .197
4.000
5.311 — 2.618 M30X2-6G
2.886
.811
140-53-21
Spline has helix on tooth. End yokes will be a tight fi t.
4.500 .134
4.000
5.312
2 2.625
1.250-18
2.875
.812
6.5-53-171
Spline has helix on tooth. End yokes will be a tight fi t.
4.500 .259
4.000
5.312
2 2.625
1.250-18
2.875
.812
6.5-53-181
Spline has helix on tooth. End yokes will be a tight fi t.
5.197 .236
3.980
5.291
2 2.618 M30X2-6G
2.886
.812
250-53-11
Spline has helix on tooth. End yokes will be a tight fi t.
2.560 Bearing Diameter (C)
3.500 .134
6.703
7.000
1 2.469
.500-20
3.125
1.234 4-53-301•
2.750 Bearing Diameter (C)
4.500 .259
5.490
6.310
2 2.750
1.250-18
3.620
—
6.5-53-201•
2.360-16 Spline
2.361 Bearing Diameter (C)
4.000 .134
4.688
7.562
2 3.000
1.250-18
3.000
1.188 6-53-271
2.500-10 Spline
2.559 Bearing Diameter (C)
4.500 .134
6.281
7.000
2 2.938
1.500-18
3.500
1.500 6.5-53-111
2.578-25 Involute Spline
2.749 Bearing Diameter (C)
4.095 .180
5.781
6.500
2 2.500
1.625-12
3.125
—
6-53-371
2.656-18 Involute Spline
2.756 Bearing Diameter (C)
4.500 .259
4.562
6.000
2 2.875
1.500-18
3.312
.812
8-53-61
