Yokes
55
New Service Carriers Tandem Drive Axles
Yokes & Flanges
All D344, 404, 405, 454, DSP40, DSP41, DSH40, DSH44, DST40 and DST41 Tandem Axle Series
Forward Axle - Input / 44 - 2.250 Involute Spline
Production Service
Yoke & Slinger Part Dimensions (in inches):
Slinger Assy Number Series Style A B C Replacement Notes
127550 6-4-8981-1X 1710 23° Y 5.19 1.94 6.09
127617 6-4-8981-1X 1710 30° X 5.19 1.94 6.19
127618 6.3-4-5221X 1760 30° Y 5.25 1.94 7
127619 6.5-4-4571X 1810 30° Y 5.25 1.94 7.55
127620 5-4-9261-1X 1610 35° X 5 1.88 5.31
127621 6.5-4-4571-1X 1810 30° X 5.25 1.94 7.64
127622 6.3-4-5221-1X 1760 30° X 5.25 1.94 7.09
210831 170-4-201-1X SPL170 25° X 5.27 2.16 5.51
210833 250-4-81-1X SPL250 25° X 5.49 2.36 5.31
Forward Axle - Output / 39 - 1.950 Involute Spline
Production Service
Yoke & Slinger Part Dimensions (in inches):
Slinger Assy Number Series Style A B C Replacement Notes
127558 6-4-9041X 1710 30° Y 5.25 1.94 6.09
127624 6-4-9001X 1710 45° Y 6.12 1.94 6.09
127638 5-4-9271X 1610 45° Y 6 1.88 5.31
128722 6-4-9001-1X 1710 39.5° X 6.12 1.94 6.19
128737 6-4-9041-1X 1710 30° X 5.25 1.94 6.19
210835 170-4-221-1X SPL170 25° X 5.27 2.16 5.51
210837 170-4-241-1X SPL170 45° X 6.5 2.16 5.51
All R344, 404, 405, 454 and 17/19/21/22060S/D/A, RSP40, RSP41, RSH40, RSH44
Rear Axle - Input / 39 - 1.95 Involute Spline
Production Service
Yoke & Slinger Part Dimensions (in inches):
Slinger Assy Number Series Style A B C Replacement Notes
127415 6-4-9031X 1710 30° Y 5.25 1.94 6.09
127637 6-4-8991X 1710 45° Y 6.12 1.94 6.09
128720 5-4-9241X 1610 45° Y 6 1.88 5.31
128721 128721 1610 22° Y 4.72 1.88 5.31
128745 6-4-9031-1X 1710 30° X 5.25 1.94 6.19
128746 6-4-8991-1X 1710 39.5° X 6.12 1.94 6.19
129019 5-4-9241-1X 1610 45° X 6 1.88 5.31
129043 5-4-9231-1X 1610 23° X 4.88 1.88 5.31
129164 3-4-13081-1X 1480 19° X 4.34 1.38 3.69
129166 4-4-7571-1X 1550 24.5° X 4.3 1.38 4.47
210839 170-4-261-1X SPL170 25° X 5.16 2.16 5.51
210841 170-4-281-1X SPL170 45° X 6.24 2.16 5.51
210923 90-4-251-1X SPL90 15° X 4.75 1.61 4.53
