47
New Service Carriers Tandem Drive Axles
Tandem Drive Axle - Single Reduction Carriers
D190D - Diff Lock Carrier
18.50" Ring Gear Diameter
Side Gear # 300GD101
These new carrier units will directly replace tandem forward
models D52-190D, D60-190D with no modifications. (See Note 1)
Side Gear New
Ratio Spline Carrier Notes
3.42 46 Inv 681082
3.58 46 Inv 681083
3.73* 46 Inv 681084
3.91* 46 Inv 681085
4.10 46 Inv 681086
4.30* 46 Inv 681087
4.56 46 Inv 681088
4.78 46 Inv 681089
5.25* 46 Inv 681090
5.38 46 Inv 681091
5.57 46 Inv 681092
6.14 46 Inv 681093
6.83 46 Inv 681094
7.17 46 Inv 681095
*Most commonly used ratios in On-Hwy vehicle applications.
Note 1: Dana D190D Forward models with diff-lock come standard
with lube pump. Serial tags for production axles do not carry the
traditional "P" designation in the model identifier.
S190D - Diff Lock Carrier
18.50" Ring Gear Diameter
Side Gear # 300GD101
Note: Drive Axle Tag may read R46-190D
These new carrier units will directly replace tandem rear-rear
models R46-190D, R52-190D, R60-190D and single axle models
S23-190D, S26-190D, and S30-190D with no modifications.
Side Gear New
Ratio Spline Carrier Notes
2.53 46 Inv 681478
2.69 46 Inv 681231
2.87 46 Inv 681232
2.93 46 Inv 681233
3.07 46 Inv 681234
3.21 46 Inv 681235
3.42 46 Inv 681237
3.58 46 Inv 681238
3.73* 46 Inv 681239
3.91* 46 Inv 681240
4.10 46 Inv 681241
4.30* 46 Inv 681242
4.56* 46 Inv 681243
4.78 46 Inv 681244
5.25* 46 Inv 681245
5.38 46 Inv 681246
5.57 46 Inv 681247
6.14 46 Inv 681248
6.83 46 Inv 681249
7.17 46 Inv 681250
7.83 46 Inv 681251
*Most commonly used ratios in On-Hwy vehicle applications.
