50
New Service Carriers Tandem Drive Axles
Tandem Drive Axle
Double Reduction Carriers
DP402(P) - Planetary Double Reduction
16.00" Spiral Bevel Gearing (3.36-3.70 Ratio)
16.50" Spiral Bevel Gearing (3.90-7.17 Ratio)
Side Gear # 110527
See Note 1: These new carrier units will directly replace models
DP402(P), DP381(P) and DP451(P) built with 41 Involute spline
side gears with no modifications.
Side Gear Non-Pump New Carrier
Ratio Spline New Carrier w/Pump
5.05 41 Inv 675548 NA
5.32 41 Inv NA 675551
5.61 41 Inv 675542 675266
5.91 41 Inv 675271 676131
Note 1: In Nov. 1995, the models DT/RT451(P) and DP/
RP451(P) were produced in both 33 and 41 Involute side gear
configurations. Before ordering a service carrier verify correct
spline count.
RP402 - Planetary Double Reduction ( USE
RT402 AND 122680 ENGAGEMENT KIT)
USE RT402 Service Carriers below plus 122680
Engagement Kit
16.00" Spiral Bevel Gearing (3.36-3.70 Ratio)
16.50" Spiral Bevel Gearing (3.90-7.17 Ratio)
Side Gear # 110527
These new carrier units can be used to replace RP402 and
RP451. Order the RT402 carrier below and install Dana 122680
Engagement Kit.
Side Gear New RT402
Ratio Spline Carrier Notes
3.70/5.05 41 Inv 674698 plus 122680 kit
3.90/5.32 41 Inv 674558 plus 122680 kit
4.11/5.61 41 Inv 674559 plus 122680 kit
4.33/5.91 41 Inv 674560 plus 122680 kit
DP461P - Plantary Double Reduction and No
Spin Carrier
18.00" Spiral Bevel Gearing
Side Gear # 118959
No Spin # 126211
These new carrier units can be used as a replacement for DP461P,
DP462P, DP463P, DP521P, DP601P, DP651P, DP652P and
DP461P NS, DP462P NS & DP463P NS no spin carriers with no
modifications. (NOTE 1)
Side Gear New With
Ratio Spline Carrier No Spin
5.04 36 Inv 674954 509382
5.31 36 Inv 674953
5.60 36 Inv 674952
5.90 36 Inv 674790
6.20 36 Inv 674936 508003
6.64 36 Inv 674951
7.39 36 Inv 674949
8.40 36 Inv 674950
Note 1: Models DP/RP650, DP/RP580 were made with 39 Involute
side gears. If a service carrier with 39 Involute is not available,
models DP461/RP461 with 36 Involute spline side gears can
be used as a replacements, but the axle shafts must also be
replaced. See Axle Shaft IPL AXIP-0078 for part number listing.
