32
New Service Carriers Single Drive Axles
Single Axle - High Entry Carriers
S170E - High Entry Carrier
18.00" Ring Gear Diameter
Side Gear # 300GD101
These new carrier units directly replace single axle models S21-
170E, S23-170E with no modifications.
Side Gear New
Ratio Spline Carrier Notes
3.07 46 Inv 681483
3.21 46 Inv 681484
3.31 46 Inv 681485
3.42 46 Inv 681486
3.58 46 Inv 681487
3.73 46 Inv 681488
3.91 46 Inv 681489
4.10 46 Inv 681490
4.30 46 Inv 681491
4.56 46 Inv 681492
4.78 46 Inv 681493
5.25 46 Inv 681494
5.38 46 Inv 681495
5.57 46 Inv 681496
6.14 46 Inv 681497
6.83 46 Inv 681498
7.17 46 Inv 681499
S190DE - High Entry with Diff Lock Carrier
18.50" Ring Gear Diameter
Side Gear # 300GD101
These new carrier units will directly replace single axle models
S23-190DE, S26-190DE and S30-190DE with no modifications.
Side Gear New
Ratio Spline Carrier Notes
3.42 46 Inv 681138
3.58 46 Inv 681139
3.73* 46 Inv 681140
3.91* 46 Inv 681141
4.10 46 Inv 681142
4.30 46 Inv 681143
4.56 46 Inv 681144
4.78 46 Inv 681145
5.25 46 Inv 681146
5.38 46 Inv 681147
5.57 46 Inv 681148
6.14* 46 Inv 681149
6.83 46 Inv 681150
7.17 46 Inv 681151
S190E - High Entry Carrier
18.50" Ring Gear Diameter
Side Gear # 300GD101
These new carrier units will directly replace single axle models
S23-190E, S26-190E and S30-190E with no modifications.
Side Gear New
Ratio Spline Carrier Notes
3.58 46 Inv 681125
4.56 46 Inv 681130
4.78 46 Inv 681131
5.38 46 Inv 681133
5.57 46 Inv 681134
6.14 46 Inv 681135
7.17 46 Inv 681137
