31
New Service Carriers Single Drive Axles
Single Axle - Double Reduction Carriers
23080P - Double Reduction and No Spin Carrier
18.00" Spiral Bevel Gearing
Side Gear # 118959
Pinion Seal # 210724
No Spin # 126211
See Note 1. These new carrier units will directly replace single axle
models 23080P, 26080P, 26085P, 35055P (for 23327, 35327 see
NOTE 1).
Side Gear New With
Ratio Spline Carrier No Spin
5.04 36 Inv 674977
5.31 36 Inv 675512
5.60 36 Inv 674932
5.90 36 Inv 674671
6.20 36 Inv 674937 211557
6.64 36 Inv 674672
7.39 36 Inv 674673
8.40 36 Inv 675225
9.08 36 Inv 674674
Note 1: Models 23327, 35327 were made with 39 Involute side
gears. If a replacement carrier with 39 Involute is not available, the
23080P models with 36 Involute spline side gears can be used as
a replacements, but the axle shafts must also be replaced. See
Axle Shaft IPL AXIP-0078 for part number listing.
S590 - Double Reduction Carrier
18.50" Ring Gear Diameter
Side Gear # 300GD101
These new carrier units will directly replace single axle models
S23-590, S26-590, S30-590, S35-590 and can replace rear-rear
tandem models R46-590, R52-590, R60-590, R70-590 with no
modifications.
Side Gear New
Ratio Spline Carrier Notes
4.75 46 Inv 681152
4.99 46 Inv 681153
5.19 46 Inv 681154
5.44 46 Inv 681155
5.70 46 Inv 681156
5.98 46 Inv 681157
6.34 46 Inv 681158
6.65* 46 Inv 681159
7.30 46 Inv 681160
7.48 46 Inv 681161
7.75 46 Inv 681162
8.55 46 Inv 681163
9.51* 46 Inv 681164
9.97 46 Inv 681165
10.90* 46 Inv 681276
S590D - Double Reduction with Diff Lock Carrier
18.50” Ring Gear Diameter
Side Gear # 300GD101
These new carrier units will directly replace single axle models
S23-590D, S26-590D, S30-590D and S35-590D and replace
rear-rear tandem models R52-590D, R60-590D, R70-590D with no
modifications.
Side Gear New
Ratio Spline Carrier Notes
4.75 46 Inv 681166
4.99 46 Inv 681167
5.19 46 Inv 681168
5.44 46 Inv 681169
6.34* 46 Inv 681391
6.65 46 Inv 681393
8.55* 46 Inv 681392
10.90* 46 Inv 681277
*Most popular ratios
