23
New Service Carriers Single Drive Axles
Single Axle - Single Reduction Carriers
21060S NS - No Spin Carrier
15.50" Hypoid Gearing
No Spin Diff # 128776
These new carrier units will directly replace single axle models
21060S NS and 22060S NS with no modifications.
Side Gear No Spin
Ratio Spline Carrier Notes
3.90 41 Inv 511236
4.11 41 Inv 511237
4.33 41 Inv 511238
4.63 41 Inv 511239
4.88 41 Inv 511240
5.29 41 Inv 511241
5.57 41 Inv 511242
6.17 41 Inv 511243
Note: The service carriers listed above have a thin flange design.
Use axle housing hardware kit 511600.
21060S BC - GenTech™ - Quiet Gearing
15.50" Hypoid Gearing
Side Gear # 127368
See Note 1. These new carrier units will directly replace single axle
models 21060S BC (GenTech - Coach Quiet) with no modifications.
(See Note 2)
Side Gear New
Ratio Spline Carrier Notes
4.30 41 Inv 675629* BC, No Yoke
4.30 41 Inv 675917* BC, w/Yoke 5-4-9241X (128720)
4.30 41 Inv 675919* BC, w/Yoke 6-4-8991X (127637)
4.63 41 Inv 681462 BC, No Yoke
4.78 41 Inv 675873* BC, No Yoke
4.78 41 Inv 675918* BC, w/Yoke 5-4-9241X (128720)
5.29 41 Inv 675924* BC, w/Yoke 5-4-9241X (128720)
5.29 41 Inv 676145* BC, No Yoke
5.57 41 Inv 681459 BC, No Yoke
6.17 41 Inv 676149* BC, No Yoke
6.50 41 Inv 676150* BC, No Yoke
7.17 41 Inv 676151* BC, No Yoke
* Denotes thin flange design - use axle housing hardware kit
511600. All others are thick flange design - use axle housing
hardware kit 512087.
Note 1: Dana carriers shown with GenTech gearing are for motor
coach and bus applications. When doing repairs or replacement
of these axles, be sure to consult the OEM or verify the actual part
numbers from the serial tags before ordering carriers. For ratios
not shown call Dana for availability.
22060SH - High Performance Carrier &
GenTech™ - Quiet Gearing
15.75" Hypoid Gearing
Side Gear # 127368
See Note 1. These new carrier units will directly replace model
22060SHBC and RSH40 with no modifications.
Side Gear New Bus
Ratio Spline Carrier Coach Carrier
3.08 41 Inv 675780
3.25 41 Inv 675781
3.36 41 Inv 675782
3.55 41 Inv 675783
3.70 41 Inv 675784
3.90 41 Inv 675785
4.11 41 Inv 675786
4.33 41 Inv 675787
4.63 41 Inv 675788
4.63 41 Inv 681462 Note 1
4.88 41 Inv 675789
Note 1: Dana carriers are application specific. Some motor coach
and bus applications require Gentech gearing. When doing repairs
or replacement of these axles, be sure to consult the OEM or
verify the actual part numbers from the serial tags before ordering
replacement carriers.
