22
New Service Carriers Single Drive Axles
Single Axle - Single Reduction Carriers
21060S - Standard Carrier & Parking Brake
Option
15.50" Hypoid Gearing
Side Gear # 127368
See Note 1. These new carrier units will directly replace single axle
models 21060S, 21060S PB, 22060S and 22060S PB and tandem
axle models RS404 and RS405 with no modifications. Model on ID
tag may be RS404.
Side Gear New With
Ratio Spline Carrier PB Option
2.64 41 Inv 674877 NA
2.85 41 Inv 674878 NA
2.93 41 Inv 675635 NA
3.08 41 Inv 674879 NA
3.25 41 Inv 674880 NA
3.36 41 Inv 674881 681516*
3.55 41 Inv 674882 676121*
3.70 41 Inv 674883 676122*
3.90 41 Inv 674884 676123*
4.11 41 Inv 674885 676124*
4.33 41 Inv 674886 676125*
4.63 41 Inv 674887 676126*
4.88 41 Inv 674888 676127*
5.29 41 Inv 674889 676128*
5.57 41 Inv 674890 676129*
6.17 41 Inv 674891 NA
6.50 41 Inv 674892 681283*
7.17 41 Inv 674893 NA
* Denotes thin flange design - use axle housing hardware kit
511600. All others are thick flange design - use axle housing
hardware kit 512087.
Note 1: In certain Navistar applications, original Dana Production
Carriers are identified as 21060S, 21060L, 21060T and 21060D.
These carriers are built with 39 Involute spline side gears. Carriers
with 39 Involute spline side gears are sold as 19060S, 19060BC,
19060L, 19060T and 19060D. Refer to the 19060 model section
of this IPL for those replacement part numbers. Be sure to check
spline configuration before ordering a replacement carrier.
21060D - Diff Lock Carrier & Parking Brake
Option
15.50" Hypoid Gearing
Side Gear # 127368
See Notes 1 & 2. These new carrier units will directly replace
differential lock single axle models 21060D, 21060D PB, 22060D
and 22060D PB and tandem axle models RD404 and RD405 with
no modifications. Model on ID tag may be RD404.
Side Gear New With
Ratio Spline Carrier PB Option
2.64 41 Inv 676013 NA
2.85 41 Inv 675281 NA
3.08 41 Inv 675282 NA
3.25 41 Inv 675283 NA
3.36 41 Inv 675284 NA
3.55 41 Inv 675285 681300*
3.70 41 Inv 675286 681299*
3.90 41 Inv 675287 681301*
4.11 41 Inv 675288 681302*
4.33 41 Inv 675289 681303*
4.63 41 Inv 675290 681304*
4.88 41 Inv 675291 681305*
5.29 41 Inv 675292 681306*
5.57 41 Inv 675293 681307*
6.17 41 Inv 675294 NA
6.50 41 Inv 675295 681308*
7.17 41 Inv 675296 NA
* Denotes thin flange design - use axle housing hardware kit
511600. All others are thick flange design - use axle housing
hardware kit 512087.
Note 1: In certain International applications, original Dana
Production Carriers are identified as 21060S, 21060L, 21060T
and 21060D. These carriers are built with 39 Involute spline side
gears. Carriers with 39 Involute spline side gears are sold as
19060S, 19060BC, 19060L, 19060T and 19060D. Refer to the
19060 section of this IPL for those replacement part numbers. Be
sure to check spline configuration before ordering a replacement
carrier.
Note 2: Diff Lock shift covers on these units are supplied with
standard English threaded air line ports.
