52
New Service Carriers Tandem Drive Axles
Tandem Drive Axle
Double Reduction Carriers
D590 - Double Reduction Carrier
18.50" Ring Gear Diameter
Side Gear # 300GD101
These new carrier units will directly replace forward models D46-
590, D52-590, D60-590, D70-590 with no modifications.
Side Gear New
Ratio Spline Carrier Notes
4.75 46 Inv 681096
4.99 46 Inv 681097
5.19 46 Inv 681098
5.44 46 Inv 681099
5.70 46 Inv 681100
5.98 46 Inv 681101
6.34* 46 Inv 681102
6.65* 46 Inv 681103
7.30 46 Inv 681104
7.48 46 Inv 681105
7.75 46 Inv 681106
8.55* 46 Inv 681107
9.51 46 Inv 681108
9.97 46 Inv 681109
10.90* 46 Inv 681419
*Most popular ratios
R590 - Double Reduction Carrier
18.50" Ring Gear Diameter
Side Gear # 300GD101
These new carrier units will directly replace rear-rear tandem
models R46-590, R52-590, R60-590, R70-590 and single
axle models S23-590, S26-590, S30-590, S35-590 with no
modifications.
Side Gear New
Ratio Spline Carrier Notes
4.75 46 Inv 681152
4.99 46 Inv 681153
5.19 46 Inv 681154
5.44 46 Inv 681155
5.70 46 Inv 681156
5.98 46 Inv 681157
6.34 46 Inv 681158
6.65* 46 Inv 681159
7.30 46 Inv 681160
7.48 46 Inv 681161
7.75 46 Inv 681162
8.55 46 Inv 681163
9.51* 46 Inv 681164
9.97 46 Inv 681165
10.90* 46 Inv 681276
D590D - Double Reduction with Diff Lock Carrier
18.50" Ring Gear Diameter
Side Gear # 300GD101
These new carrier units will directly replace forward models D52-
590D, D60-590D and D70-590D with no modifications.
Side Gear New
Ratio Spline Carrier Notes
4.75 46 Inv 681110
4.99 46 Inv 681111
5.19 46 Inv 681112
5.44 46 Inv 681113
5.70 46 Inv 681114
5.98 46 Inv 681115
6.34 46 Inv 681116
6.65* 46 Inv 681117
7.30* 46 Inv 681118
7.48 46 Inv 681119
7.75 46 Inv 681120
8.55* 46 Inv 681121
9.51 46 Inv 681122
9.97 46 Inv 681123
10.90 46 Inv Call for Availability
*Most popular ratio
R590D - Double Reduction with Diff Lock Carrier
18.50” Ring Gear Diameter
Side Gear # 300GD101
These new carrier units will directly replace rear-rear tandem
models R52-590D, R60-590D, R70-590D and single axle
models S23-590D, S26-590D, S30-590D and S35-590D with no
modifications.
Side Gear New
Ratio Spline Carrier Notes
4.75 46 Inv 681166
4.99 46 Inv 681167
5.19 46 Inv 681168
5.44 46 Inv 681169
6.34* 46 Inv 681391
6.65 46 Inv 681393
8.55* 46 Inv 681392
10.90* 46 Inv 681277
*Most popular ratios
