Spicer Drive System Illustrated Parts List ESD D386, D406, D466, DS4026, DS4616, DS_DC_DT4636, 6x6 - Manual (Page 8)

8
DS
3416-P
Oty. 386-P DS DS
Item Per 4026-P 446-P 4616-P
No. Part Name Axle 406-P 466-P 5216-P
56 Output Shaft Bearing Cup (Inner) 1 110811* 24328* 24328*
57 Output Shaft Bearing Cone (Inner) 1 110812* 24330* 24330*
58 Output Shaft Side Gear 1 110810 78911 78911
59 Inter-axle Diff. Assy. 1 104509 104597 121681
Includes Items 61-66
60 DIFF. CASE KIT
Includes Items 60-62
1 94810 106470 —
(Case Half- NSS) 2 102621 104513 126151
61 Case Bolt 8 85438 57636 57636
62 Case Nut 8 57637 57637 57637
DIFF. SIDE PINION & SPIDER KIT
Includes Items 63-66
1 96381 96382 —
63 Spider 1 95216 95220 126152
64 Side Pinion Bushing 4 95215* 95219* —
65 Side Pinion 4 95214 95218 95218
66 Side Pinion Thrust Washer 4 85437* 27810* 126180*
67 Helical Side Gear Snap Ring 1 85997* 78909* 78909*
68 Helical Side Gear & Bushing Assy 1 110844 113331 113331
Includes Item 69
(Side Gear- NSS)
110843 113328 113328
69 Helical Side Gear Bushing 2 85991 75063* 75063*
70 Helical Side Gear Thrust Washer 1 85429* 79034* 79034*
71 Helical Side Gear ‘D’ Washer 1 45478* 56360* 56360*
72 Lockout Sliding Clutch 1 45480 119948 119948
73 INPUT SHAFT KIT 1 115126 121301 122418
Includes Item 91
(Shaft - NSS)
110805 119947 119990
74 Input Shaft Bearing Cone 1 91136* 98387* 98387*
75 Cover & Plug Assy 1 113602 113603 113603
Includes Items 79-80
(Cover- NSS)
111300 111360 111360
76 Cover Cap Screw
Short
4 90069 —
Short 8 — 90069 90069
Long 4 12063
Long 1 — 9309 9309
Socket Head 1 81855 81855 81855
77 Lockwasher 9 90417
Lockwasher 10 — 90417 90417
78 Dowel PIn 2 7641 7641 7641
79 Pipe Plug 1 90325 90325 90325
80 Expansion Plug 1 9797 9797 9797
81 Magnetic Filter Screen 1 102611* 102611* 102611*
82 Input Shaft Bearing Cup 1 98388* 98388* 98388*
83 Input Bearing Cover Shim AR
.003 ′ 45498* 78918* 78918*
.005 ′ 70709* 78919* 78919
.010 ′ 45499* 78920* 78920*
.020 ′ 85406* 113130* 113130*
OIL SEAL KIT
Includes Items 83 & 108 & 119429,119855 & RTV
1 114395 — —
84 Input Bearing Cover, Cup
& Oil Seal Assy
1 110808 111691 111691
Includes Items 82 & 87
(Cover- NSS)
110807 111690 111690
85 Bearing Cover Cap Screw 5 113324 113324 126243
86 Lockwasher 5 — 90414 90414
