Spicer Drive System Illustrated Parts List ESD D386, D406, D466, DS4026, DS4616, DS_DC_DT4636, 6x6 User Manual
Page 19
19
DC
3416-P
Oty.
386-P*
DS
DC
Item
Per
4026-P
446-P*
4616-P
No.
Part Name
Axle
406-P*
466-P*
5216-P
94
Lockout Sliding Clutch
1
45480
119948
119948
95
INPUT SHAFT KIT
1
115126
121301
122418
Includes Item 112
(Shaft - NSS)
110805
119947
119990
96
Input Shaft Bearing Cone
1
91136*
98387*
98387
97
Cover & Plug Assy
1
113602
113603
113603
Includes Items 101-102
(Cover- NSS)
111300
111360
111360
98
Cover Cap Screw
Short
4
90069
—
Short
8
—
90069
90069
Long
4
12063
Long
1
—
9309
9309
Socket Head
1
81855
81855
81855
99
Lockwasher
9
90417
—
Lockwasher
10
—
90417
90417
100
Dowel Pin
2
7641
7641
7641
101
Pipe Plug
1
90325
90325
90325
102
Expansion Plug
1
9797
9797
9797
103
Magnetic Filter Screen
1
102611
102611*
102611
104
Input Shaft Bearing Cup
1
98388*
98388*
98388
105
Input Bearing Cover Shim
AR
.003
′
45498*
78918*
78918
.005
′
70709*
78919*
78919
.010
′
45499*
78920*
78920
.020
′
85406*
113130*
113130
106
Input Bearing Cover, Cup
& Oil Seal Assy
1
110808
111691
111691
Includes Items 104,109
(Cover- NSS)
110807
111690
111690
107
Bearing Cover Cap Screw
4
113324
113324
126243
108
Spacer Washer
4
111776
109
Input Shaft Oil Seal
1
119429*
119430*
119430
110
Input Yoke & Slinger
1
See OEM Catalog
111
Flat Washer
1
85404*
79699*
126242
112
Input Shaft Nut
1
95207
95209
126155
113
Lockout Assembly (see page 42)
1
104600
104819
104819
Includes Items 115-117
114
Shift Fork Assembly
1
102613
103529
103529
115
Cap Screw
2
90031
90031
90031
116
Lockwasher
2
90415
90415
90415
117
Bearing Cup
1
111295
111355
111355
118
Bearing Cone
1
111296
111296
111356
119
Helical Gear
1
119895
111358
111358
120
Front Output Shaft
1
119894
119994
119994
121
Lockout Clutch
1
45480
45480
45480
122
Bearing Cone
1
111308
91136
91136
123
Bearing Cup
1
111295
90951
90951
124
Yoke Spacer
1
30453
—
125
Output Cage Shim
AR
.003
′
111301
111362
111362
.005
′
111302
111363
111363
.010
′
111303
111364
111364
.020
′
111304
111365
111365
.030
′
111305
111366
111366
