33
RT/RP RT/RP
3416 4616
Oty. 386 RT/RP 5216
Item Per 4026 446 6016
No. Part Name Axle 406 466 6516
37 Diff. Case Cap Screw 8 96283 — —
4 — 96285 96285
8 — 96284 96284
WHEEL DIFF. KIT
Includes Items 38-42
1 — 114474 119393
R3416 1 114469 — —
R386, R4026 1 114470 — —
R406 1 98853 — —
WHEEL DIFF. SIDE PINION KIT
Includes Items 39-42
1 118748 118750 118751
38 Diff. Side Gear 2 — 110528 108959
R3416 2 110525 — —
R388, R4026 2 110527 — —
R406 2 85486 — —
39 Side Gear Thrust Washer 2 27827* 18198* 83726*
40 Side Pinion 4 104139 96900 108142
41 Side Pinion Thrust Washer 4 27810* 18199* 108145*
42 Spider 1 38289 107371 108141
43 Pinion Pilot Bearing 1 15828* 126187* 126187*
44 Pinion Bearing Cone (Inner) 1 12496* 27239* 27239*
Pinion Bearing Cone (Outer) 1 12496* 14218* 14218*
45 Pinion Bearing Spacer Washer 1 — 31366* 31366*
46 Pinion Bearing Spacer AR
(see page 13)
47 Pinion Bearing Cup (Inner) 1 12495* 27238* 27238*
Pinion Bearing Cup (Outer) 1 12495* 14217* 14217*
48 Pinion Bearing Cage & Cup Assy.
Includes Item 47 (Cage. NSS)
Ratios 3.55-3.70 (Cage 75107)
1 75108 —
Other Ratios (Cage 75109) 1 75110 —
Ratios 3.70-4.88 (Cage 79245) 1 — 79246 —
Other Ratios (Cage 104470) 1 — 104471 —
All Ratios (Cage 210591) 1 — — 210592
49 Pinion Bearing Cage Shim AR
.003 ′ 107567* 67920* 67920*
.005 ′ 107568* 67921* 67921*
.010 ′ 107569* 67922* 67922*
.020 ′ 107570* 67923* 67923*
50 Bearing Cage Cap Screw 6 113325 113327 113327
51 Lockwasher 6 37207 90422 90422
OIL SEAL & SHIM KIT
(Includes Items 49 & 52)
1 115453 115582 122425
52 Oil Seal 1 119427* 119432* 113866*
53 Yoke 1 See OEM Catalog
54 Flat Washer 1 56864* — 210509
55 Pinion Nut 1 95206 95262 210508
Gasket Compound AR 107276* 107276* 107276*
BASIC OVERHAUL KIT 1 110585* 110598* 122424*
(Includes above parts with *)
