Spicer Drive System Illustrated Parts List ESD D386, D406, D466, DS4026, DS4616, DS_DC_DT4636, 6x6 - Manual (Page 29)

29
DT/DP DT/DP
3416-P 4616-P
Oty. 386-P DT/DP 5216-P
Item Per 4026-P 446-P 6016-P
No. Part Name Axle 406-P 466-P 6516-P
101 Input Bearing Cover Shim AR
.003 ′ 45498* 78918* 78918*
.005 ′ 70709* 78919* 78919*
.010 ′ 45499* 78920* 78920*
.020 ′ 85406* 113130* 113130*
102 Input Bearing Cover, Cup
& Oil Seal Assy
1 110808 111691 111691
Includes Items 100,105
(Cover- NSS)
110807 111690 111690
103 Bearing Cover Cap Screw 5 113324 113324 126243
OIL SEAL & SHIM KIT 1 114395
Includes Items 101,105
104 Lockwasher 5 — 90414 90414
105 Input Shaft Oil Seal 1 119429* 119430* 119430*
106 Spacer Washer 1 — — 111776
107 Yoke 1 See OEM Catalog
108 Flat Washer 2 85404* 79599* 126242*
109 Input Shaft Nut 1 95207 95209 126155
110 Lockup Assembly (see page 42-43)
Includes Items 111-113
1 — — —
111 Shift Fork Assembly 1 102613 103529 103529
112 Cap Screw 2 90031 90031 90031
113 Lockwasher 2 90415 90415 90415
114 Bearing Cup 1 111295 111355 111355
115 Bearing Cone 1 111296 111356 111356
116 Helical Gear 1 119895 111358 111358
117 Front Output Shaft 1 119894 119994 119994
118 Lockout Clutch 1 45480 45480 45480
119 Bearing Cone 1 111308 91136 91136
120 Bearing Cup 1 111295 90951 90951
121 Yoke Spacer 1 30453 — —
122 Output Cage Shim AR
.003 ′ 111301 111362 111362
.005 ′ 111302 111363 111363
.010 ′ 111303 111364 111364
.020 ′ 111304 111365 111365
.030 ′ 111305 111366 111366
123 Front Output Cage, Cup & Seal
Assy (Includes Items 120,126)
1 111307 111369 111369
(Cage - NSS) 111306 111367 111367
124 Cap Screw 4 90069 90069 90069
125 Lockwasher 4 90417 90417 90417
126 Oil Seal 1 119431 119429 119429
127 Front Output Yoke 1 See OEM Catalog
128 Washer 1 56864 56864 210509
129 Nut 1 95206 95262 210508
130 Lockup Assembly (see page 40-41)
Includes Items 131-133
1 — — —
131 Shift Fork & Push Rod 1 111372 111372 111372
132 Cap Screw 2 21385 111313 111313
133 Lockwasher 2 90415 90415 90415
LUBE PUMP REPLACEMENT KIT 1 106368 121302 121302
Includes Items 134-141
134 Drive Gear Locknut 1 111451 111451 111451
135 Oil Pump Drive Gear 1 111448 119946 119946
