Spicer Drive System Illustrated Parts List ESD D386, D406, D466, DS4026, DS4616, DS_DC_DT4636, 6x6 - Manual (Page 16)

16
DC
3416-P
Oty. 386-P* DS DC
Item Per 4026-P 446-P* 4616-P
No. Part Name Axle 406-P* 466-P* 5216-P
1 Diff. Carrier & Bearing Caps 1 115825 106710 110501
(Carrier. NSS) 110816 110500 110500
Includes Items 1-5,14-17,19-23
2 Bearing Cap Screw 4 32732 32732 32732
3 Flat Washer 4 32912 32912 32912
4 Lockwire 4 90538 12563 12563
5 Dowel Bushing 2 32730 32730 32730
6 Adjuster Lock (RH)(S.E.&D.C.) 1 111120 45448 45448
Adjuster Lock (RH)(P.E.) 1 45448 45448 45448
7 Cap Screw (RH) 2 12562 12562 210601
8 Lockwire 2 12563 12563 12563
9 Adjuster Lock (LH) 1 13377 14275 14275
10 Dowel Bushing (LH) 1 37746 37746 —
11 Cotter Pin (LH) 1 90873 90876 90876
12 Shift Fork Shaft & ‘O’ Ring
Assy (S.E.&D.C.)
1 113801 113801 113801
Shaft 41103-NSS; ‘O’ Ring 113140
13 Expansion Plug (Upper) 1 30703* 30703* 30703
Expansion Plug (Lower) 1 9797* 9797* 9797
14 Filler Plug 1 90325 90325 90325
15 Carrier Cover Dowel Pin 2 7641 7641 7641
16 Shift Fork (S.E.&D.C.) 1 32613 84508 84508
17 Shift Fork Seal (S.E.&D.C.) 1 119855* 119855* 119855
18 Shift Unit Stud (S.E.&D.C.) 2 119863 119863 119863
19 Stud Nut (S.E.&D.C.) 2 63028 63028 63028
20 Stud Washer (S.E.&D.C.) 2 119857 119857 119857
21 Shift Unit Opening Cover (P.E.) 1 45521 45521 45521
22 Cap Screw (P.E.) 2 20807 20807 20807
23 Lockwasher (P.E.) 2 90415 90415 90415
24 Shift Unit 1 73507 73507 73507
25 Shift Fork Cover Retainer
Assy (S.E.)
1 83510 83510 83510
26 Adjusting Screw (12 Pt)(S.E.) 1 83511 83511 83511
27 Adjusting Screw Jam Nut (S.E.) 1 59600 59600 59600
28 End Nut 1 95205 95262 95262
29 Flat Washer 1 4327* — —
30 Yoke 1 See OEM Catalog
31 Bearing Retaining Washer 1 — 78922 78922
32 Output Shaft Oil Seal 1 119431* 119429* 119429
33 Snap Ring 1 45516* 78937* 78937
34 Bearing & Sleeve Assy 1 46584* 78936* 78936
35 Axle Housing Cover Assy
Includes Items 32 - 36
(Cover 77751 - NSS)
1 107320 —
(Cover 84546 - NSS) 1 — 107863 107863
36 Magnetic Filler Plug 1 75130 75130 75130
Temperature Plug 1 90898 90898 —
37 Diff. Bearing Adjuster (RH) 1 111022 21637 82451
Diff. Bearing Adjuster (LH) 1 110243 90898 21637
38 Diff. Bearing Cup (RH) 1 27816* 21632* 21632
Diff. Bearing Cup (LH) 1 9803* 15092* 15092
39 Diff. Bearing Cone (RH) 1 27817* 102660* 102660
Diff. Bearing Cone (LH) 1 27813* 27876* 27876
