44
Shift Unit
Oty.
Item per Unit Unit Unit
No. Part Name Axle 73503 73505 73507
Piston Air Shift Assy 1 73503 73505 73507
Electric Over Air or Straight Air
Includes Items 1-26
1 Cover Assy (Includes Item 2) 1 73486 73486 73487
2 Cover Bearing 1 73481 73481 73481
3 Self-tapping Screw & Washer Assy 7 88053 88053 88053
4 Cover Gasket 1 73488 73488 73488
5 Cover Plug 1 28325 28325 28325
6 Actuating Lever Pin 1 73456 73456 73456
7 Clevis Pin 1 73498 73498 73498
8 Actuating Lever, Pin & Block Assy 1 84803 84803 84804
9 Shift Housing Cover 1 73490 73490 73490
10 Seal Ring 1 73492 73492 73492
11 Cover Bolt 4 73491 73491 73491
12 Locknut 4 47641 47641 47641
13 Locknut 1 73496 73496 73496
14 Washer 1 111406 111406 111406
15 Piston 1 73493 73493 73493
16 Felt Piston Oiler (Strip) 2 96916 96916 96916
17 Piston “O” Ring 1 32832 32832 32832
18 Grommet 1 32826 32826 32826
19 Push Rod 1 73497 73497 73497
20 Compression Spring 1 73494 73494 73494
21 Piston Stop 1 73495 73495 73495
22 Housing Assy (Includes Items 3 & 23) 1 82428 82428 82429
23 Housing Bearing 1 73481 73481 73481
24 Cap Screw 1 58309 — —
25 “O” Ring 1 56659 56659 —
26 Lockout Control Valve 1 — 66483 —
