11
RS
3416
Oty. 386 RS RS
Item Per 4026 446 4616
No. Part Name Axle 406 466 5216
1 Diff. Carrier & Bearing Caps 1 67804 98593 122432
(Carrier - NSS) 107172 98493 98493
Includes Items 1-5
2 Cap Screw 4 67811 32732 32732
3 Flat Washer 4 26772 32912 32912
4 Lockwire 4 90538 12563 12563
5 Dowel Bushing 2 — 32730 32730
6 Adjuster Lock (RH) 1 13377 14275 14275
Adjuster Lock (LH) 1 14275 14275 14275
7 Cotter Pin (RH) 1 90873 90876 90876
Cotter Pin (LH) 1 90876 90876 90876
8 Thrust Screw 1 — — 126193
9 Thrust Screw Jam Nut 1 — — 210184
10 Bearing Adjuster (RH) 1 110243 21637 21637
Bearing Adjuster (LH) 1 31562 39448 39448
11 Bearing Cup (RH) 1 27813* 15092* 15092*
Bearing Cup (LH) 1 90943* 19529* 19529*
12 Bearing Cone (RH) 1 21813* 27876* 27876*
Bearing Cone (LH) 1 6082* 27666* 27666*
13 RING GEAR & DRIVE PINION SET
(Matched Parts, see page 34)
RING GEAR BOLT & NUT KIT
Includes Item 14
1 70745 70745 70745
14 Bolt 16 67586 67586 67586
Nut 16 60600 60600 60600
DIFF. CASE KIT Note: 110243 adjuster
Includes Items 15-16 in 106397 & 94799
1 — 104609 —
Ratios 3.36-5.29 1 106397 — —
Ratios 5.57-7.17 1 94799 — —
Ratios 3.70-4.11 1 — — 98610
Ratios 4.33-6.17 1 — — 121845
15 Diff. Case (Plain Half - NSS) 1 110138 104518 86777
Diff. Case (Flanged Half - NSS)
Ratios 3.36-5.29
1 103865 — —
Ratios 5.57-7.17 1 88677 — —
Ratios 3.70-4.11 1 — 104519 88501
Ratios 4.33-6.17 1 — 104519 126234
16 Cap Screw 12 96271 96284 88503
WHEEL DIFF. KIT.
Includes Items 17-21
1 — 114474 114472
R3416 1 114469 — —
R386, R4026 1 114470 — —
R406 1 98853 — —
WHEEL DIFF. LESS SIDE & GEAR KIT
Includes Items 18-21
1 118748 118750 118749
17 Side Gear 2 — 110528 93401
R3416 2 110525 — —
R386, R4026 2 110527 — —
R406 2 85486 — —
18 Side Gear Thrust Washer 2 27827* 18198' 27274*
19 Side Pinion 4 104139 96900 86780
20 Side Pinion Thrust Washer 4 27810* 18199* 86781*
21 Spider 1 38289 107371 86778
22 Pilot Bearing 1 15828* 126187* 126187*
23 Bearing Cone (Inner) 1 12496* 27239* 27239*
Bearing Cone (Outer) 1 12496* 14218* 14218*
24 Pinion Bearing Spacer AR
(see page 13)
