Spicer Drive System Illustrated Parts List ESD D386, D406, D466, DS4026, DS4616, DS_DC_DT4636, 6x6 User Manual
Page 20
20
DC
3416-P
Oty.
386-P*
DS
DC
Item
Per
4026-P
446-P*
4616-P
No.
Part Name
Axle
406-P*
466-P*
5216-P
126
Front Output Cage, Cup & Seal
Assy (Includes Items 123,129)
111307
111369
111369
(Cage - NSS)
111306
111367
111367
127
Cap Screw
4
90069
90069
90069
128
Lockwasher
4
90417
90417
90417
129
Oil Seal
1
119431
119431
119429
130
Front Output Yoke
1
See OEM Catalog
131
Washer
1
56864
56864
210509
132
Nut
1
95206
95262
210508
133
Lockup Assembly (see page 40)
Includes Items 134 -136
1
113581
113584
113584
134
Shift Fork & Push Rod
1
111372
111372
111372
135
Cap Screw
2
21385
21385
111313
136
Lockwasher
2
90415
90415
90415
LUBE PUMP REPLACEMENT KIT
1
106368
121302
121302
Includes Items 137-144
137
Drive Gear Locknut
1
111451
111451
111451
138
Oil Pump Drive Gear
1
111448
119946
119946
139
Oil Pump Gear & Idler
Shaft Assy
1
102625
102625
102625
111779
111779
111779
140
Cover “O” Ring
1
102620*
102620*
102620
141
Cover Dowel Pin
2
102617
102617
102617
142
Pump Cover
1
102607
102607
102607
143
Lockwasher
4
90419
90419
90419
144
Cap Screw
4
102618
102618
102618
Gasket Compound
AR
107276
107276
107276
BASIC OVERHAUL KIT
1
118420*
118124*
—
Includes above parts with *
