2
MODEL IDENTIFICATION NUMBERING SYSTEM
GEAR SET IDENTIFICATION
Manufacturer's Date- Date gear set was made.
Spicer Trademark- Company logo and location of
manufacturing facility.
Part number of pinion- 390GP100 (TYPICAL)
Tooth Combination(i.e. 41-11)
- Indicates the pinion
has 11 teeth and the ring gear has 41 teeth which
results in a 3:73:1 ratio.
Matched Set Number- Spicer ring gears and pinions
are manufactured as matched sets. Both ring gear and
pinion are marked with a corresponding number (i.e.
260), which identifies them as a matched set.
A gear set that does not have the same match set
numbers should not be run together. If either ring gear
or pinion require replacement, a new matched set must
be used.
Backlash etch- Indicates backlash setting for assembly.
HEAT
CODE
SPICER
TRADEMARK
MFG.
DATE MATCHED
SET NUMBER
PART
NUMBER
TOOTH
COMBINATION
41-11
260
SPICER
TRADEMARK
+15
L10
PINION ETCH
BACKLASH ETCH
260
Op Op Op Op Options tions tions tions tions
(N = *No-SPIN (N = *No-SPIN (N = *No-SPIN (N = *No-SPIN (N = *No-SPIN ® ® ® ® ® Differ Differ Differ Differ Differential) ential) ential) ential) ential)
S 400 S N
Gearing T Gearing T Gearing T Gearing T Gearing Type ype ype ype ype
(S = Single R (S = Single R (S = Single R (S = Single R (S = Single Reduc educ educ educ eduction) tion) tion) tion) tion)
FFFFFamil amil amil amil amilyyyyy
(S = Spicer) (S = Spicer) (S = Spicer) (S = Spicer) (S = Spicer)
Nominal Load Nominal Load Nominal Load Nominal Load Nominal Load
Carr
Carr Carr Carr Carrying Capacit ying Capacit ying Capacit ying Capacit ying Capacityyyyy
(400 = 40,000 Lbs.) (400 = 40,000 Lbs.) (400 = 40,000 Lbs.) (400 = 40,000 Lbs.) (400 = 40,000 Lbs.)
* No-SPIN ® is a registered trademark of Tractech
