Adventurer Pro EN-9
2.2.4 Assembly of Models AV212
Note: Assembly instructions also apply to models with the suffix C, CR, CU, R or U.
1. Insert the Sub-platform on the Mounting Cone located in the center of the balance.
2. Place the Weighing Pan on the Sub-platform.
3. Place the Wind ring over the shoulder of the balance.
2.3 Selecting the Location
Locate the balance on a firm, steady surface. Avoid locations with excessive air current, vibrations,
heat sources, or rapid temperature changes.
2.4 Leveling the Balance
Before the balance is used, the feet should be adjusted so that the scale is level with the surface.
This will enable accurate weighing. You will see a level bubble indicator in a small round
window on the front of the balance. Level the balance by adjusting the leveling feet so the bubble
is centered in the circle, as seen below.
Balance Level
Weighing Pan
Sub-platform
Wind ring
Mounting Cone
