Users can zoom in and out in three different ways:
• using the Zoom command in the Toolbar
• using the Zoom bar at the bottom left of the Ingest Scheduler window
• rotating the mouse wheel on the Timeline and Ingest Overview area
Depending on the chosen time period, all the ingest blocks are redrawn to respect a new
time scale.
Lock Nowline Button
In the Timeline and Ingest Overview area, the current date/time is represented by a blue
line, called the Nowline. The timeline can be displayed in two different ways depending on
whether the nowline has been locked or not.
Nowline Mode Nowline Behavior
Locked By clicking the Lock Nowline button (colored background) the
nowline stays locked in the middle of the Timeline and Ingest
Overview area. The ingest blocks move from right to left across the
line to keep the current date/time in the middle.
Unlocked When the Lock Nowline button appears with a white background,
the nowline moves from left to right across the screen. Ingest
blocks keep their places on the screen.
Go to Now
When the nowline is not locked, it is possible to jump to the current time with the nowline
in the middle of the screen by clicking the Go to Now button.
Go to [Date]
