Issue 4.0.B

Xedio Dispatcher – Version 4.0 – User’s Manual

EVS Broadcast Equipment – July 2011

64

Filter Button Display Meaning

(dimmed)

The Show/Hide Filter button is dimmed when all filter

criteria are hidden. Consequently, the filters are inactive.

(red)

The Show/Hide Filter button is red when the filter

extended area is visible, even if no filtering criterion is

applied.

Filter Extended Area

The Filter extended area is as follows:

The first field under the Show/Hide Filter button lists three options for the

combination of criteria to be taken into account during the filtering operation.

The second field is a filter field allowing the users to select a first filter parameter.

Criteria Combination

The available options are detailed in the table below:

Option

Meaning

ALL criteria are met

All the criteria selected in the Filter fields displayed

under the Criteria Combination field must be met.
The media displayed in the results list fulfill all the

selected filter criteria.

ANY criteria is met

At least one of the criteria selected in the Filter fields

must be met.
The media displayed in the results list fulfill at least one

of the selected filter criteria.

NO criteria is met

None of the criteria selected in the Filter fields displayed

under the Criteria Combination field must be met.
The media displayed in the results list fulfill none of the

selected filter criteria.

Filter Fields

Under the Criteria Combination field, the users will be able to select as many

filter parameters as they want and to choose specific value(s) for these filter

parameters. The use of Filter fields is explained in the next section.
