User Interface
Element
Description
Remember
Color
Selection
checkbox When the checkbox is selected, the focus will be placed by default on
the selected color square next time the Create a New Log window
opens.
Note
Two users can work on the same logsheet at the same time
with different states of the Remember Color Selection
checkbox and different colors associated to the checkbox.
Description To add alphanumeric free text from the keyboard.
This will appear in the Description column of the logsheet for the
corresponding log, as well as in the Description field of the Log
Information tab when a log line is selected.
Keywords Up to 10 keywords can be added per event.
To add a keyword, select it from the Keyword Grid or Keyword
Dictionary or type its first letters and select it from the Autocomplete
list. See section "Assigning a Keyword to a Media" on page 78 for
more information on how to assign keywords to media.
They will appear in the Keywords columns of the logsheet for the
corresponding log.
Automatic
Keywords Displays the user fields defined for the logsheet profile associated to
the logsheet.
1.4.3. LIVE Logging with PC Timecode
Context of Use
When, for example, you want to log an event with just a laptop in a hotel room, watching
the event on a regular TV set, you can use the PC time as the timecode for the logs.
You must then create a logsheet with no relevant recorder channel defined. As the
IPLogger is not linked to an EVS video server, it has no timecode information and you will
not be able to make log entries. The NEW button in the LIVE area is disabled.
How to Link Logs to PC Timecode
To link the logs to the PC timecode, proceed as follows:
1. Click the Link To PC Timecode button.
The Logsheet Video Format window appears:
24 1. IPLogger
