16

|

Installation and Startup

NOTE:

Keep the software CD, communication cable, and (if needed) REPO connectors in the accessory box

until you install the UPS.

1

2

13

Install the UPS front cover:

Align the front cover with the front of the chassis.

Insert the right-side tabs on the front cover into tab openings on the right-side chassis.

Push the left side of the cover forward and snap it to the chassis.

NOTE:

Ensure that the LCD panel on the UPS chassis aligns with the LCD window on the front cover before

securing the cover to the chassis.

14

Discard or recycle the packaging in a responsible manner, or store it for future use.
