24 | English
1 609 929 V11 | (23.8.11) Bosch Power Tools
Noise/Vibration Information
Measured sound values determined according to EN 60745.
Typically the A-weighted noise levels of the product are:
Sound pressure level 95 dB(A); Sound power level
103 dB(A). Uncertainty K =2 dB.
Wear hearing protection!
Vibration total values a
h
(triax vector sum) and uncertainty K
determined according to EN 60745:
a
h
=6 m/s 2 , K=1.5 m/s 2 .
The vibration emission level given in this information sheet
has been measured in accordance with a standardised test
given in EN 60745 and may be used to compare one tool with
another. It may be used for a preliminary assessment of expo-
sure.
The declared vibration emission level represents the main ap-
plications of the tool. However if the tool is used for different
applications, with different accessories or poorly maintained,
the vibration emission may differ. This may significantly in-
crease the exposure level over the total working period.
An estimation of the level of exposure to vibration should also
take into account the times when the tool is switched off or
when it is running but not actually doing the job. This may sig-
nificantly reduce the exposure level over the total working pe-
riod.
Identify additional safety measures to protect the operator
from the effects of vibration such as: maintain the tool and the
accessories, keep hands warm, organise work patterns.
Declaration of Conformity
We declare under our sole responsibility that the product de-
scribed under “Technical data” is in conformity with the fol-
lowing standards or standardization documents: EN 60745
according to the provisions of the directives 2011/65/EU,
2004/108/EC, 2006/42/EC, 2000/14/EC.
EC Type Certification No. 3400653.02 CE by notified testing
agency No. 2140, KEMA Quality GmbH Dresden.
2000/14/EC: Guaranteed sound power level 105 dB(A).
Conformity assessment procedure according to Annex V.
Equipment category: 6
Technical file (2006/42/EC, 2000/14/EC) at:
Robert Bosch GmbH, PT/ESC,
D-70745 Leinfelden-Echterdingen
Robert Bosch GmbH, Power Tools Division
D-70745 Leinfelden-Echterdingen
26.07.2011
Assembly
For Your Safety
f Warning! Switch off, remove plug from mains before
adjusting cleaning or if the cable is cut, damaged or en-
tangled.
f Caution! Do not touch the rotating chain.
f Do not operate the chain saw near other people, chil-
dren or animals. Do not operate the chain saw after
drinking alcohol or under the influence of intoxicating
drugs or medication.
Your machine is double insulated for safety and requires no
earth connection. The operating voltage is 230 V AC,
50/60 Hz (for non-EU countries 240 V as applicable). Only
use approved extension cables. Contact your Bosch Service
Centre for details.
When operating the chain saw with an extension cable, the
following conductor cross-sections are required:
– min. 1.5 mm
2 to a max. cable length of 50 m
– min. 2.5 mm 2 to a max. cable length of 100 m
Note: If an extension cable is used it must be earthed and con-
nected through the plug to the earth cable of your supply net-
work in accordance with prescribed safety regulations.
When using cable drums, these must be completely unreeled.
Only extension cables of design type H07 RN-F or IEC (60245
IEC 66) are permitted for use.
If in doubt contact a qualified electrician or the nearest Bosch
Service Centre.
f
WARNING! Inadequate extension cables can be dan-
gerous. Extension cable, plug and socket must be of
watertight construction and intended for outdoor use.
Cable connections should be kept dry and off the ground.
Soft starting z z
Constant electronic control z z
Weight according to EPTA-Procedure 01/2003 kg 4.6 4.8
Protection class /II /II
Chain saw GKE 35 BCE
Professional
GKE 40 BCE
Professional
*limited via electronic control
The values given are valid for a nominal voltage [U] of 230 V. For different voltages and models for specific countries, these values can vary.
Please observe the article number on the type plate of your machine. The trade names of the individual machines may vary.
Dr. Egbert Schneider
Senior Vice President
Engineering
Dr. Eckerhard Strötgen
Head of Product
Certification
