48
ASRock Z77 Extreme6/TB4 Motherboard
2.18.2 Installing Windows ® 8 / 8 64-bit / 7 / 7 64-bit / Vista TM /
Vista TM 64-bit Without RAID Functions
If you want to install Windows ® 8 / 8 64-bit / 7 / 7 64-bit / Vista TM / Vista TM 64-bit OS
on your SATA / SATA2 / SATA3 HDDs without RAID functions, please follow the
steps below.
Using SATA / SATA2 / SATA3 HDDs with NCQ function
STEP 1: Set Up UEFI.
A. Enter UEFI SETUP UTILITY Advanced screen Storage Configuration.
B. Set the option “SATA Mode Selection” to [AHCI]. (For SATA2_2 to SATA2_5,
SATA3_0 and SATA3_1 ports.)
Set the option “ASMedia SATA3 Mode” to [AHCI]. (For SATA3_A1 and SATA3_A2
ports.)
STEP 2: Install Windows
® 8 / 8 64-bit / 7 / 7 64-bit / Vista TM / Vista TM 64-bit OS on
your system.
Using SATA / SATA2 / SATA3 HDDs without NCQ function
STEP 1: Set Up UEFI.
A. Enter UEFI SETUP UTILITY Advanced screen Storage Configuration.
B. Set the option “SATA Mode Selection” to [IDE]. (For SATA2_2 to SATA2_5,
SATA3_0 and SATA3_1 ports.)
Set the option “ASMedia SATA3 Mode” to [IDE]. (For SATA3_A1 and SATA3_A2
ports.)
STEP 2: Install Windows
® 8 / 8 64-bit / 7 / 7 64-bit / Vista TM / Vista TM 64-bit OS on
your system.
