Step4. Connect a VGA cable or a DVI cable to the monitor connector or the DVI
connector of the graphics card that is inserted to PCIE1 slot.
Step3. Align and insert the ASRock SLI_Bridge Card to the goldfingers on each
graphics card. Make sure the ASRock SLI_Bridge Card is firmly in place.
ASRock SLI_Bridge Card
