Replacing Light Bulbs Headlight Bulbs
250
M
ain
te
n
an
ce
Low Beam Headlights
1. Turn the steering wheel all the way to the
opposite side from the headlight being
replaced.
Passenger side: Turn the steering wheel
to the left.
Driver side: Turn the steering wheel to
the right.
2. Remove the holding clips and screws, and
pull the inner fender back.
3. Rotate the cover to the left, and remove.
Low Beam Headlights
High voltage can remain in the circuit for a long period of time after the light is
switched off. Do not attempt to inspect or replace the high voltage discharge type
bulbs yourself. Ask a dealer to inspect and replace low beam headlights.
Low Beam Headlights
When removing the clip, insert a flat-tip screwdriver,
and lift and remove the central pin.
High Voltage Discharge Type
Halogen Type
Inner Fender
Screw
Cover
Clip
