XHardware Health Configuration
This feature allows the user to monitor Hardware Health of the system and review the status of each
item when displayed.
CPU Overheat Alarm
This option allows the user to select the CPU Overheat Alarm setting which de- termines when the
CPU OH alarm will be activated to provide warning of possible CPU overheat.
Warning: Any temperature that exceeds the CPU threshold temperature predefined by the
CPU manufacturer may result in CPU overheat or system instability. W hen the CPU tempera
ture reaches this predefined threshold, the CPU and system cooling fans will run at full speed.
The options are:
o The Early Alarm: Select this setting if you want the CPU overheat alarm (includ- ing the LED and
the buzzer) to be triggered as soon as the CPU temperature reaches the CPU overheat threshold as
predefined by the CPU manufacturer.
o The Default Alarm: Select this setting if you want the CPU overheat alarm
(including the LED and the buzzer) to be triggered when the CPU temperature reaches about 5oC
above the threshold temperature as predefined by the CPU manufacturer to give the CPU and sys-
tem fans additional time needed for CPU and system cooling. In both the alarms above, please take
immediate action as shown below.
CPU Temperature
The CPU Temperature feature will display the CPU temperature status as detected by the BIOS.
System Temperature
This feature displays the absolute system temperature (i.e., 34oC).
Low - This level is considered as the 'normal' operating state. The CPU temperature is well below
the CPU 'Temperature Tolerance'. The motherboard fans and CPU will run normally as configured in
the BIOS (Fan Speed Control).
User intervention: No action required.
Medium - The processor is running warmer. This is a 'precautionary' level and generally means that
there may be factors contributing to this condition, but the CPU is still within its normal operating
state and below the CPU 'Temperature Tolerance'. The motherboard fans and CPU will run normally
as configured in the BIOS. The fans may adjust to a faster speed depending on the Fan Speed
Control settings.
