Active State Power Management

Select Enabled to start Active-State Power Management for signal transactions between L0 and L1
Links on the PCI Express Bus. This maximizes power-saving and transaction speed. The options are
Enabled and Disabled.

Reserved Page Route

This feature allows the user to decide which bus to send debug information to. The options are Dis-
abled, PCI and LPC.

USB Functions

This feature allows the user to decide the number of onboard USB ports to be en- abled. The Options
are: Disabled, 2 USB ports, 4 USB ports, 6 USB ports, 8 USB ports, 10 USB ports, and 12 USB
ports.

Legacy USB Support (available if USB Functions above is Enabled)

Select Enabled to use Legacy USB devices. If this item is set to Auto, Legacy USB support will be
automatically enabled if a legacy USB device is installed on the motherboard, and vise versa. The
settings are Disabled, Enabled and Auto.

USB Controller

This feature allows the user to Enable or Disable the onboard USB controller. The options are Enabled
and Disabled. Note: This function is grayed-out if USB Func- tions above is set to Enabled.

XIDE/SATA Configuration

When this submenu is selected, the AMI BIOS automatically detects the presence of the IDE Devices
and displays the following items:

SATA#1 Configuration

If Compatible is selected, it sets SATA#1 to legacy compatibility mode, while se- lecting Enhanced
sets SATA#1 to native SATA mode. The options are Disabled, Compatible, Enhanced.

Configure SATA#1 as

This feature allows the user to select the drive type for SATA#1. The options are IDE, RAID and AHCI.
