PCI IDE Bus Master
When enabled, the BIOS uses PCI bus mastering for reading/writing to IDE
Disabled and Enabled.
ROM Scan Ordering
This item determines what kind of option ROM activates over another. Therst
and Add-on First.
PCI Slot 1
Use this feature to enable or disable PCI slot Option ROMs. The options ad.
Load Onboard LAN 1 Option ROM/ Load Onboard LAN 2 Option ROM
Select Enabled to load the onboard LAN Option ROM for the LAN port as e
Enabled and Disabled.
Initiate Graphics Adapter
Use this feature to select the graphics controller to be used as the primary s
are Other, Onboard VGA and Slot 6. Select Slot 6 if a graphics controller is installed in the CPU-
controlled Slot 6 slot.
XSuper IO Configuration
Serial Port1 Address/ Serial Port2 Address
This option specifies the base I/O port address and the Interrupt Request and Serial Port 2. Select Disabled to prevent the serial port from accessing any system resources.
When this option is set to Disabled, the serial port physically becomes unavailable. Select 3F8/IRQ4
to allow the serial port to use 3F8 as its I/O port address and IRQ 4 for the interrupt address. The
options for Serial Port1 are Disabled, 3F8/IRQ4, 3E8/IRQ4, 2E8/IRQ3. The options for Serial Port2
are Disabled, 2F8/IRQ3, 3E8/IRQ4, and 2E8/IRQ3.
XRemote Access Configuration
Remote Access
This allows the user to enable the Remote Access feature. The options are.
If Remote Access is set to Enabled, the following items will display:
Serial Port Number
This feature allows the user decide which serial port to be used for Console
Redirection. The options are COM 1, COM 2 and COM 3.
