4. How to Use
User Guide Page 4-1
4. Using RAIDGuardX GUI
After you have connected all your ExaSAN components, powered the system on, and installed the
RAIDGuardX drivers, we will first need to perform some basic configuration and setup before the
ExaSAN RAID system is fully operational.
Figure 33: GUI “Main screen”
Function Description
1
Add Controller Add RAID controller/system to RAIDGuard X
Remove Controller Remove RAID controller/system from RAIDGuard X
2
Create Array Create an array from disk drives in the storage system
Delete Array Delete an array in the storage system
3 Email Set email notification
4 Preference
Drive Lag Proof Enable/ Disable Drive Lag Proof
NCQ Mode Enable/ Disable NCQ mode
SMART Mode Enable/ Disable SMART Mode
Beeper Enable/ Disable Beeper
Equalization Enable/ Disable Equalization
