Bosch IOS 0232 A RS232 Communication Module User Manual
Page 19
Latviski
4.998.137.267
IOS 0232 A, produkta apraksts
19 / 32
ST − FIR / PRM1 / deh
610−4.998.153.975 / A2
Funkcionâlais apraksts
d RS232 komunikâciju modulis nodroðina divus neatkarîgus RS232 interfeisus, lai pievienotu
printeri un/vai piezîmjdatoru.
Vadojums
Pozîcija
Maríçjums
Savienojums
15
RXD1
16
TXD1
RS232 1. interfeiss
17
GND
20
RXD2
21
TXD2
RS232 2. interfeiss
22
GND
DSUB 9 spraudòu kontakta spraudòu nozîme
Spraudnis Nr.
Savienojums
2
TxD0
3
RxD0
5
GND
Tehniskâ specifikâcija
Ieejas spriegums (minimâlais − maksimâlais)
20 V DC − 30 V DC
Maksimâlais strâvas patçriòð
2,6 mA
Maksimâlais lîniju garums
3 m (3,28 jardi) katram interfeisam
Droðîbas klase
II, saskaòâ ar IEC 60950 / EN 60950
EMI / EMC aizsardzîba
EN 50081−1 / FCC Part 15
Aizsardzîbas klase
IP 30, saskaòâ ar IEC 60529
Darba temperatûra
−5
_C . . . 50 _C (23 _F . . . 122 _F)
Uzglabâðanas temperatûra
−20
_C . . . 60 _C (23 _F . . . 140 _F)
Pieïaujamais relatîvais mitrums
maks. 95%, nekondensçjoðs
Apvalka materiâls un krâsa
ABS plastmasa Polylac PA−766 (UL94 V−0),
daïçji glancçts antracîts, RAL 7016
Izmçri (A x P x D)
aptuveni 127 x 96 x 60 mm (5,0 x 3,8 x 2,4 collas)
Svars
aptuveni 180 g (6,3 unces)
15 16 17
20 21 22
5
4
3
2
1
9
8
7
6
