7-2
C
HAPTER
7: C
ONFIGURING
DHCP
The OfficeConnect Remote 840 can be configured to support up to 40
workstations on the local LAN. In addition, the OfficeConnect Remote
840 can be configured to be a DHCP Relay.
When enabled, the Relay will process the broadcast request from the
local workstation and send it to one or two remote DHCP servers. The
response from the remote DHCP servers is processed and forwarded to
the local workstation.
Configuring the
DHCP Mode
The OfficeConnect Remote 840 has three DHCP modes; Server, Relay,
and Disable. To configure the mode, select Configuration > Global >
DHCP from the home page. The following screen will be shown:
To configure the OfficeConnect Remote 840 as a Server, select Server >
Submit > Configure DHCP Server to proceed with Server specific
settings (see
).
To configure the OfficeConnect Remote 840 as a Relay, select Relay >
Submit > Configure DHCP Relay to proceed with Relay specific settings
(see
).
Select the Disable button and press the submit button to disable the
OfficeConnect Remote 840's DHCP functionality.
