3Com 3C840 - Manual (Page 59)

Configuring IP RIP on the LAN 4-5
Configuring IP RIP
on the LAN RIP is utilized as a means of communicating routing information between
routers. This is done to keep the routers updated on information.
Local Site (LAN) RIP The RIP options for the LAN can be accessed through Configuration >
Local Site > IP. Select a defined local site connection from the list and
click Modify/Delete, which accesses the IP Modify/Delete screen,
containing the following fields:
You can then select the RIP version to be either None, RIPV1, or RIPV2.
You can also modify the Advanced RIP parameters. You should not need
to change any of these parameters from the defaults, but you can if
necessary.
Advanced RIP
Modification Options
Select a local site connection from the list on the main IP screen, and click
Advanced.
