9-2 C HAPTER 9: C ONFIGURING IPX R OUTING
Configuring IPX for
the LAN To configure IPX over the LAN, assign an IPX network to the LAN port by
providing a name and a network address. After adding a network you
can modify advanced parameters.
In order for the OfficeConnect Remote 840 to route traffic, you also have
to set up a corresponding network over the WAN port. (See
“Configuring
IPX for Remote Sites Connection” .)
Use the Configuration > Local Site (LAN) > IPX screen to define or
modify all IPX networks over the LAN. Note that each IPX network
defined over the LAN must support a different frame type.
Adding a Local IPX
Network
To add a Local IPX network:
1 From the OfficeConnect Remote 840 home page, select Configuration
> Local Site (LAN) > IPX. Click Add. This brings up a screen with the
following fields:
2 Enter a name for the network, the IPX address of the network, and the
frame type of the network running on the LAN. Check the Enable IPX
box.
3 Click Add to add this defined IPX network.
For information of configuring the IPX RIP and SAP, see “Configuring IPX
RIP and SAP” .
