7.4
U s e r G u i d e
C H A N G I N G A N I N K C A R T R I D G E
Insert the green base of the ink cartridge, heel
first, into the correct location on the color print
head. The ink cartridges and corresponding
locations are color-coded and numbered.
Push the ink cartridge down until it clicks into
place.
To close the WorkCentre cover, lift up to release
the support arms and push down until completely
closed. Your WorkCentre will automatically
begin cleaning the print heads.
The control panel on the WorkCentre will now
lead you through a series of instructions for
alignment.
6
Caution: Do not force the ink cartridge
into the print head.
7
4
3
8
9
