Chapter 17 Event Logging
ES-1528 User’s Guide
99
Figure 53 Logging - Add Server
The following table describes the labels in this screen.
17.4 Viewing RAM and Flash Logs
Use these screens to view or export RAM or Flash logs. Click the RAM or Flash link in the
Logging screen to view the following screen (Logs - RAM is shown here).
Figure 54 Logging - RAM/Flash
Table 34 Logging - Add Server
LABEL DESCRIPTION
Name Enter a short descriptive name for identifying this server.
IP Address Enter the IP address in dotted decimal notation of the syslog server you want to add.
Port Specify the UDP port for sending log messages to this server. Typically port 514 is
used with syslog.
Facility The log facility allows you to send logs to different files in the syslog server. Refer to
the documentation of your syslog server for more details.
Add Click Add to save this entry to the switch and return to the Logging screen.
