Chapter 18 SNMP
ES-1528 User’s Guide
116
Figure 69 SNMP Trap Station
The following table describes the labels in this screen.
18.6.1 SNMP Trap Station - Create
Click on the Create New Trap Station link in the SNMP Trap Station screen to add an
SNMP Trap Station. The screen displays as shown.
Figure 70 SNMP Trap Station - Create
Table 51 SNMP Trap Station
LABEL DESCRIPTION
Trap Station ID Select the SNMP trap station you want to edit.
Create New
Trap Station
Click this to configure a new SNMP Trap Station.
Trap Station ID This field indicates the trap station number. It is used for identification only. Click on
the individual trap station number to edit the trap station settings.
Remote IP
Address
This field displays the IP address of the remote SNMP management station.
Community
String
An SNMP community string is a text string that acts as a password. It is used to
authenticate messages that are sent between the management station (the SNMP
manager) and the device (the SNMP agent). The community string is included in
every packet that is transmitted between the SNMP manager and the SNMP agent.
This field displays the community string of this remote trap station.
Previous Page/
Next Page
Use these navigation links to browse all of your SNMP groups.
