Chapter 19 RMON-Lite
ES-1528 User’s Guide
132
19.7.1 RMON Event Log : Event
Use the RMON Event Log : Event screen to view the details of existing RMON event log
entries. Click on the specific Event Index numbers in the RMON Event Log : Overview
screen to view the screen as shown.
Figure 83 RMON Event Log : Event
The following table describes the labels in this screen.
Last Time Sent This field indicates the value of system up time on the switch when this event was
last generated. It appears in the following format “XXD: XXH: XXM: XXS”, where
“XX” stands for a number and “D” stands for days, “H” for hours, “M” for minutes and
“S” for seconds.
Owner This field displays the entry creator. It displays “monitor” if the entry was created by
the switch itself.
Table 64 RMON Event Log : Overview (continued)
LABEL DESCRIPTION
Table 65 RMON Event Log : Event
LABEL DESCRIPTION
RMON MIB
Table:
Use this drop down list box to select the MIB table you want to view. Click Apply to
refresh the screen to the selected MIB table view.
Refresh Click this to update all the fields in the RMON Event Log : Event Index screen.
Log Index This field displays a log index number.
Log Time This field displays the time a log was generated.
Log Description This field displays an implementation dependent description of the event that
activated this log entry.
Event Log
Overview
Click this to view the RMON Event Log : Overview screen.
