Chapter 3 Hardware Overview
ES-1528 User’s Guide
39
Gigabit Ethernet Ports
100/1000 Green On The link to a 10/1000 Mbps Ethernet network is up.
Amber On The link to a 100 Mbps Ethernet network is up.
Off The link to an Ethernet network is down.
ACT Green On The link to an Ethernet network is up.
Blinking The Ethernet port is transmitting/receiving data.
Off The link to an Ethernet network is down.
GBIC Slots
LNK Green On The port has a successful connection.
Off No Ethernet device is connected to this port.
ACT Green Blinking The port is receiving or transmitting data.
Table 2 LEDs (continued)
LED COLOR STATUS DESCRIPTION
