Chapter 13 Level 2 (L2) Management
ES-1528 User’s Guide
85
Figure 47 Display L2 Address Table
The following table describes the labels in this screen.
Table 27 Display L2 Address Table
LABEL DESCRIPTION
Reload
Address Table
Click this to update all the fields in the L2 Address table.
Item This is the index number of the MAC address entry.
Source MAC This field displays the MAC address.
VID This field displays the VID of a manually entered MAC address entry.
Port This field displays the port number of a MAC address entry or it displays HOST if its
the entry for the switch itself.
Type This field displays whether this entry was entered manually into the L2 address table
- static or whether it was learned by the switch - dynamic.
