025-39022-001 Harness Wiretrack, 12 ga, 3 wire, 1’ LG. 12
025-39022-002 Harness Wiretrack, 12 ga, 3 wire, 2’ LG. 24
025-39022-003 Harness Wiretrack, 12 ga, 3 wire, 3’ LG. 36
025-39022-004 Harness Wiretrack, 12 ga, 3 wire, 4’ LG. 48
025-39022-005 Harness Wiretrack, 12 ga, 3 wire, 5’ LG. 60
025-39022-006 Harness Wiretrack, 12 ga, 3 wire, 6’ LG. 72
025-39022-007 Harness Wiretrack, 12 ga, 3 wire, 7’ LG. 84
025-39022-008 Harness Wiretrack, 12 ga, 3 wire, 8’ LG. 96
025-39022-009 Harness Wiretrack, 12 ga, 3 wire, 9’ LG. 108
025-39022-010 Harness Wiretrack, 12 ga, 3 wire, 10’ LG. 120
025-39022-011 Harness Wiretrack, 12 ga, 3 wire, 11’ LG. 132
025-39022-012 Harness Wiretrack, 12 ga, 3 wire, 12’ LG. 144
025-39022-013 Harness Wiretrack, 12 ga, 3 wire, 13’ LG. 156
025-39022-014 Harness Wiretrack, 12 ga, 3 wire, 14’ LG. 168
025-39022-015 Harness Wiretrack, 12 ga, 3 wire, 15’ LG. 180
025-39022-016 Harness Wiretrack, 12 ga, 3 wire, 16’ LG. 192
025-39022-017 Harness Wiretrack, 12 ga, 3 wire, 17 LG. 204
025-39022-018 Harness Wiretrack, 12 ga, 3 wire, 18’ LG. 216
025-39022-019 Harness Wiretrack, 12 ga, 3 wire, 19’ LG. 228
025-39022-020 Harness Wiretrack, 12 ga, 3 wire, 20’ LG. 240
386-02271-001 Harness, Wiretrack Tee Kit N/A
WIRING-HARNESSES LIGHT ASSEMBLY - WIRE TRACK
PART-NUMBER DESCRIPTION DIM A
INCHES
MALE
TERMINAL
END
TERMINAL
FEMALE
END
DIM "A" ± .50
3.0 ± .50
3.0 ± .50
FIG. 20 - HARNESS-WIRETRACK LDO9709
