Door latching parts – York LDO9688 User Manual
Page 13
13
YORK INTERNATIONAL
FORM 102.20-RP1(1104)
DOOR LATCHING PARTS
REF #
DOOR
HT*
HANDLE**
LOCK
SWING
PART NUMBER
DESCRIPTION
1
SHORT
OR TALL
STD OR
SINGLE
STD
OUT
034-12001-001
Handle,Type_L,Lock_Non,Out-Swg,Roller_
Straight,W/Screw & Cover Plug.
1
SHORT
OR TALL
STD OR
SINGLE
STD
IN
034-12001-006
Handle,Type_L,Lock_Non,In-Swg ,Roller_Off-
Set,W/Screw & Cover Plug.
1
SHORT
OR TALL
STD OR
SINGLE
KEY
OUT
034-12001-007
Handle,Type_L,Lock_Key,Out-Swg,Roller_
Straight,W/Screw & Cover Plug, Key The
Same,York Std.
1
SHORT
OR TALL
STD OR
SINGLE
KEY
IN
034-12001-010
Handle,Type_L,Lock_Key,In-Swg , Roller_Off-
Set,W/Screw & Cover Plug, Key The Same,York
Std.
1
SHORT
OR TALL
STD OR
SINGLE
PAD
OUT
034-12001-011
Handle,Type_L,Lock_Pad,Out-Swg, Roller_
Straight,W/Screw & Cover Plug.
1
SHORT
OR TALL
STD OR
SINGLE
PAD
IN
034-12001-012
Handle,Type_L,Lock_Pad,In-Swg ,Roller_Off-
Set,W/Screw & Cover Plug.
1
SHORT
OR TALL
SINGLE
KEY
OR
STD
IN OR
OUT
034-12002-007
Plug, Cover For Latch Mechanism
2
SHORT
OR
TALL
N/A
N/A
N/A
034-12002-001
Mechanism, Latching,Includes Bushing, Lock
nut, & Jam Nut.
3
SHORT
OR
TALL
N/A
N/A
N/A
034-12002-009
3/8 Sae Flat Washer
4
SHORT
OUT
N/A
N/A
034-12002-011
Single Point Roller Cam, Snub Nose Outswing
Doors Only
5
SHORT
OR
TALL
SINGLE
N/A
N/A
034-12002-010
Linkage Adapter For 8 Mm (0.315”) Dia Rods
6
SHORT
OR
TALL
STD OR
SINGLE
N/A
N/A
034-12001-005
Inside Handle W/ Red Plastic Grip
7
SHORT
OR
TALL
SINGLE
N/A
OUT
034-12002-007
Cover Plug For Latching Mechanism For Single
Point To Cover Outside Latching Mech.
8
20.88
SINGLE
N/A
N/A
086-02023-001
Rod 0.315” Dia 10” Long Zinc Plated
8
23.88
SINGLE
N/A
N/A
086-02023-002
Rod 0.315” Dia 13” Long Zinc Plated
8
26.88
SINGLE
N/A
N/A
086-02023-003
Rod 0.315” Dia 16” Long Zinc Plated
8
29.88
SINGLE
N/A
N/A
086-02023-004
Rod 0.315” Dia 19” Long Zinc Plated
8
32.88
SINGLE
N/A
N/A
086-02023-005
Rod 0.315” Dia 22” Long Zinc Plated
8
35.88
SINGLE
N/A
N/A
086-02023-006
Rod 0.315” Dia 25” Long Zinc Plated
8
38.88
SINGLE
N/A
N/A
086-02023-007
Rod 0.315” Dia 28” Long Zinc Plated
8
41.88
SINGLE
N/A
N/A
086-02023-008
Rod 0.315” Dia 31” Long Zinc Plated
8
44.88
SINGLE
N/A
N/A
086-02023-009
Rod 0.315” Dia 34” Long Zinc Plated
8
47.88
SINGLE
N/A
N/A
086-02023-010
Rod 0.315” Dia 37” Long Zinc Plated
8
50.88
SINGLE
N/A
N/A
086-02023-011
Rod 0.315” Dia 40” Long Zinc Plated
8
53.88
SINGLE
N/A
N/A
086-02023-012
Rod 0.315” Dia 43” Long Zinc Plated
Continued on next page
