FIG. 4 - THRUST RESTRAINT INSTALLATION FOR
COMEFRI AND INDUSTRIAL FANS DISCHARG-
ING INTO PANELS
LDO9701-1
1. TH REST SUPPORT FLANGE IS TO BE FLUSH WITH PANEL OPENING.
NOTE 1
TH REST SUPPORT
FAN
021-01481-000
021-01267-000
THRUST REST BRKT
021-01267-000
021-01155-000
021-19307-000
HEX NUT
LOCK NUT
HEX NUT
LOCK WASH
FLAT WASH
TH REST SUPPORT
FLAT WASH
LOCK WASH
HEX NUT
021- 19515-000
STEEL ROD
FLAT WASHER
DISCH PANEL
FAN
RACEWAY
FLAT WASH
HEX NUT
LOCK NUT
A
TOP VIEW OF DETAIL A
DETAIL A
STEEL CUP
NEOPRENE CUP
