FORM 102.20-RP1(1104)
YORK INTERNATIONAL 36
SPLICE & SPLIT BASERAIL KITS
KIT PART
NUMBER
DESCRIPTION *
ITEM
PART
NUMBER
DESCRIPTION QTY.
386-17216-008 Split/splice Kit
Baserail 6” Only
With Lifting 12 021-01163-000 Wash, Lk Th Int 1/2 Hvy Stl Zinc Pltd., Std. C-76 12
13 021-02860-000 Nut, Hex 1/2-13 Hvy 7/8 Stl Zinc Pltd., Std. C-85 12
11 021-17728-000 Scr Hex 1/2-13unc-2a X 1.75” Sae J429 12
5 029-21340-000 Lug,lifting,baserail, For 6” Baserail Only 4
386-17216-009 Split/splice Kit
Baserail 8” & 10”
Only With Lifting 12 021-01163-000 Wash, Lk Th Int 1/2 Hvy Stl Zinc Pltd., Std. C-76 16
13 021-02860-000 Nut, Hex 1/2-13 Hvy 7/8 Stl Zinc Pltd., Std. C-85 16
11 021-17728-000 Scr Hex 1/2-13unc-2a X 1.75” Sae J429 16
5 029-21365-000 Lug,lifting,baserail, For 8” & 10” Baserail 4
386-17216-010 Split/splice Kit
Baserail 3” Only
Without Lifting 12 021-01163-000 Wash, Lk Th Int 1/2 Hvy Stl Zinc Pltd., Std. C-76 12
13 021-02860-000 Nut, Hex 1/2-13 Hvy 7/8 Stl Zinc Pltd., Std. C-85 12
11 021-17728-000 Scr Hex 1/2-13unc-2a X 1.75” Sae J429 12
10 086-02027-001 Splice Angle 3” - Baserails Splice Piece 4
386-17216-011 Splice Kit
Baserail 6” Only
Without Lifting 12 021-01163-000 Wash, Lk Th Int 1/2 Hvy Stl Zinc Pltd., Std. C-76 16
13 021-02860-000 Nut, Hex 1/2-13 Hvy 7/8 Stl Zinc Pltd., Std. C-85 16
11 021-17728-000 Scr Hex 1/2-13unc-2a X 1.75” Sae J429 16
10 086-02027-002 Splice Angle 6” - Baserails Splice Piece 4
386-17216-012 Splice Kit
Baserail 8 & 10”
Only Without
Lifting 12 021-01163-000 Wash, Lk Th Int 1/2 Hvy Stl Zinc Pltd., Std. C-76 16
13 021-02860-000 Nut, Hex 1/2-13 Hvy 7/8 Stl Zinc Pltd., Std. C-85 16
11 021-17728-000 Scr Hex 1/2-13unc-2a X 1.75” Sae J429 16
10 086-02027-003 Splice Angle 8” - Baserails Splice Piece 4
* See Shell Components Table
