Page 37
ES-2024 Series User’s Guide
37
C
H A P T E R
3
Hardware Overview
This chapter describes the front panel and rear panel of the Switch and shows you how to
make the hardware connections.
3.1 Front Panel Connection
The figure below shows the front panel of the Switch.
Figure 8 Front Panel: ES-2024A
Figure 9 Front Panel: ES-2024PWR
10/100 Mbps Ethernet Ports
Gigabit Ethernet/
Mini-GBIC Ports
Console Port
Console Port
Gigabit Ethernet/
Mini-GBIC Ports
10/100 Mbps Ethernet Ports
