Chapter 15 Link Aggregation
ES-2024 Series User’s Guide
118
15.5 Link Aggregation Control Protocol
Click in the Advanced Application > Link Aggregation > Link Aggregation Setting >
LACP to display the screen shown next. See
Section 15.2 on page 115 for more information
on dynamic link aggregation.
Figure 54 Advanced Application > Link Aggregation > Link Aggregation Setting > LACP
Port This field displays the port number.
Group Select the trunk group to which a port belongs.
Apply Click Apply to save your changes to the Switch’s run-time memory. The Switch loses
these changes if it is turned off or loses power, so use the Save link on the top
navigation panel to save your changes to the non-volatile memory when you are done
configuring.
Cancel Click Cancel to begin configuring this screen afresh.
Table 33 Advanced Application > Link Aggregation > Link Aggregation Setting (continued)
LABEL DESCRIPTION
