If 802.1Q mode is selected, some additional settings are required as follows:
----------------------------------------------------
Managed 24+2G Switch : VLAN Support Configuration
VLAN Mode : 802.1Q
IngressFilter1 IngressFilter2
Port PVID NonMember Drop Untagged Drop
------------------------------------------------------------------
PORT1
1
FORWARD
DROP
PORT2 3
FORWARD
FORWARD
PORT3 1
DROP
FORWARD
PORT4 1
DROP
FORWARD
PORT5 1
DROP
FORWARD
PORT6 1
DROP
FORWARD
PORT7 1
DROP
FORWARD
PORT8 1
DROP
FORWARD
action->
------------------------------------------------------------------
Tab=Next Item BackSpace=Previous Item Quit=Previous Menu Enter= Select Item
-------------------------------------------------------------------------
Per port control settings:
PVID : Port VID
Optional values - 1 ~ 255
Ingress Filter / NonMember Drop: Drop or forward input VLAN tagged frames whose VID does not
match PVID associated to the input port. This rule is applied only when input port is not the member port
of the associated VLAN group. Setting options - DROP, FORWARD
Ingress Filter / UnTagged Drop: Drop or forward input untagged frames
Options - DROP, FORWARD
