02_NVspec_ver202e_pdf.xls 4_Network Variables
3n Request mode
network input SNVT_hvac_mode nviMode_n;
This input network variable is used to change the operation mode of the indoor unit.
This nv is not required to use when setting the operation mode only from the local side such as the
local remote controller.
Valid Range
HVAC_AUTO:0 = Auto mode
HVAC_HEAT:1 = Heat mode
HVAC_COOL:3 = Cool mode
HVAC_PRE_COOL:5 = Dry mode
HVAC_FAN_ONLY:9 = Fan mode
:Else = Fan mode
*The range of mode setting differs depending on the model of the indoor and outdoor units.
Default Value
The default value is determined by the state of the air conditioner (indoor unit).
This variable becomes value = 0 until the value is updated after the power supply of LM-AP.
4n
Mode state
network output SNVT_hvac_mode nvoMode_n;
This output network variable indicates the present mode of the indoor unit.
Valid Range
HVAC_AUTO:0 = Auto mode
HVAC_HEAT:1 = Heat mode
HVAC_COOL:3 = Cool mode
HVAC_PRE_COOL:5 = Dry mode
HVAC_FAN_ONLY:9 = Fan mode
HVAC_NULL:0xFF = Value not available
*The value is 0 while LM-AP is initialized.
When Transmitted
This output network variable is transmitted promptly as the state changes.
This variable is also transmitted as the state changes by the operation from the local such as the local
remote controller.
This variable is output by the ncilnitStartTm (Initialize Start Time) at the powering of LM-AP.
Update Rate Update Rate Update Rate Update Rate
The value defined by nciSndHrtBt_1 (Send Heartbeat_1) is valid.
Default Service Type
Acknowledged
WLN01-1023(Ver2.02) - 10 -
